Technical Parameter
-Electrical Specification and Connections
Control Mode:
Internationalstandard DMX512
Channel Mode.
7/11 channels
Voltage:
AC90V-275V,50/60Hz
Power:
324W
Light Source:
RGBWA UV 6inl mixing color
Dimmer:
0-100% linear adiustment
Strobe:
Adjustable speed strobe effect
Zoom Angle:
15 -30 degrees
Housing:
High temperature resistant Cast aluminum shell
Features:
RDM remote address code
Product Size:
26x24x24 cm
Package Size:
29x29 x38 cm
Gross weight:
8.6 kg
Net weight:
9.2 kg
IP65 WATER PROOF
18 x 18W RGBWA UV
Passive heat dissipation
can/only/each
Zoom Wash Par
Stage Effects
Birthday Party/Theater/Wedding Hall
Concert/Bar Dance Hall/Hotel Decoration
Details of Parameters
Product size：26x24x24 cm
Product weight: 8.6 kg
Back Display
Overall with signal wire electric line display
Stainless steel metal anti-interference PG interface
Dual Chassis
Regional function display
SPLIT CASE
The light source and the power supply area are separated from each other, and the heat dissipation fins are densely packed to increase the heat dissipation area! Ensure that the lamp life is more durable!
Zero Noise
The whole solid cast aluminum shell
is a heat sink
Zoom Effect
"Linear silent motor 15~30 angle zoom Three groups of independent channel LED modules circle control color"
Stage Effects
"Large Area Dyeing And Paving Integrated With Light Beam Make up a colorful art stage"
ColorDisplay
"RGBWA +UV 6in1 Mixing 18pcs LED light source"
Outdoor Effect
"The first choice for outdoor dyeing par lighting Suitable for various scenarios Hydrophobic coating shell/Thick base plate/Vacuum barrier"
Function Display
"The whole function of the back is specific Each key function"
Show Details
"Metal PG interface Waterproof button Safety fixture"
Internal display
"Adopt wide voltage power supply, international general large capacitor Constant current anti-signal interference motherboard Using high-quality lamp beads light source, longer life"
Packing List
Each process undergoes strict verificationEvery part is carefully selected
Flight Case
DIY Service
Equipped with silent 360 degree wheels + brake lockers
Note: This is DIY service,
please consult customer service for details!
